1 / 8 Atlas Titon Hand Chain Hoist | 2 Ton x 10' Lift
The Atlas Titon Hand Chain Hoist - 2 Ton x 10' Lift is part of our Hand Chain Hoists line in the Chain Hoists department. It is rated with a working load limit of 4,400 lbs. and a Grade Grade 80 alloy chain rating. Construction: Steel with a powder-coated finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 4,400 lbs
- Grade: Grade 80 alloy chain
- Length: 10'
- Material: Steel
| SKU | HCHT210-ATLAS |
|---|---|
| Shipping weight | 39 lbs |
| Working Load Limit (lbs.) | 4400 |
| Rated for Overhead Lifting | Yes |
| Grade | Grade 80 alloy chain |
| Length | 10' |
| End Fitting | Removable safety latch hook |
| Material | Steel |
| Finish | Powder-coated |
| Color | Orange |
| Includes Load Limiter | No |
| Product Weight | 37.18 lbs. |
| Standards | Meets or exceeds all requirements of ANSI/ASME B30.16 and ASME HST-5 |
| Manufacturer Name | Atlas Lifting & Rigging |
| Brand Part Number | TCH-020-10 |
| Additional Info | 3-year warranty Number of Falls: 1 Pull to Rated Load: 405 N WLL (tons): 2 |
Shipping
Most orders ship by ground parcel; orders over 150 lbs ship by LTL truck freight with liftgate service. Shipping is calculated at checkout from the actual weight of your order. Full shipping policy.
Returns
This item is final sale. Load-bearing safety equipment can't be resold once it has left our control, so it can't be returned. If it arrives damaged or incorrect, contact us within 7 days and we'll make it right.
