1 / 3 Basket Lifting Beam - 10,000 Lb. Capacity - 12' Max Spread
The Basket Lifting Beam - 10,000 Lb. Capacity - 12' Max Spread is part of our Basket Lifting Beams line in the Lifting Beams and Spreader Bars department. It is rated with a working load limit of 10,000 lbs. Construction: Steel with a high visibility yellow powder coated paint finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 10,000 lbs
- Material: Steel
| SKU | BLB10K12 |
|---|---|
| Shipping weight | 735 lbs |
| Working Load Limit (lbs.) | 10000 |
| Safety Factor | 3:1 |
| Rated for Overhead Lifting | Yes |
| Spread | 12' |
| Bail Dimensions | Inside Width: 4" Inside Length: 7" Top Thickness: 2" |
| Material | Steel |
| Finish | High visibility yellow powder coated paint |
| Product Weight | 720 lbs. |
| Standards | Exceeds all ASME B30.20 and OSHA regulations. Proof loaded per OSHA requirements. |
| Manufacturer Name | M&W |
| Brand Part Number | 17516 |
| Additional Info | WLL (tons): 5 Headroom: 17.37" Hooks designed for 2" eye width |
