Straightpoint® 35 T Compound Plus - Bluetooth Enabled - CP35T
$7,681.79
Load Capacity77,000 lbs.
In stock — ready to ship
Secure checkout with Stripe
Parcel or LTL freight, all 50 states
The Straightpoint® 35 T Compound Plus - Bluetooth Enabled - CP35T is part of our Tension Load Cells line in the Load Cells department.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Load Capacity: 77,000 lbs.
| SKU | CP-BLE-35-T |
|---|---|
| Shipping weight | 29 lbs |
| Safety Factor | 5:1 |
| Load Capacity | 77,000 lbs. |
| Pin Size | 2-1/4" |
| Type | Standard Load Cell |
| Output | Bluetooth |
| Power Source | 4 x AA Alkaline Batteries |
| Accuracy | +/- 0.1% of Full Scale |
| Resolution | 10 lbs. |
| Range | 328' |
| Data Rate | 3Hz - up to 200Hz can be ordered for dynamic load monitorning applications |
| Operating Temperature | -10° to +50°C | 14° to 122° F |
| Battery Life | 500 hours continuous |
| Display Type | 240x128 Multi-Line Dot Matrix with Backlight |
| Product Weight | 29 lbs. |
| Standards | IP67 |
| Manufacturer Name | Crosby Straightpoint |
| Brand Part Number | CP35T-BLE / 2789011 |
Shipping
Most orders ship by ground parcel; orders over 150 lbs ship by LTL truck freight with liftgate service. Shipping is calculated at checkout from the actual weight of your order. Full shipping policy.
Returns
Unused items in original packaging can be returned within 30 days. See the return policy.
