1 / 8 1-1/4" x 18" Jaw & Eye Galvanized Turnbuckle
The 1-1/4" x 18" Jaw & Eye Galvanized Turnbuckle is part of our Galvanized Jaw & Eye line in the Turnbuckles department. It is rated with a working load limit of 15,200 lbs. Construction: galvanized finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 15,200 lbs
- Length Closed: 36.05"
- Length Open: 54.25"
- Body Length: 18"
- Diameter: 1-1/4"
| SKU | JETBGV114X18 |
|---|---|
| Shipping weight | 26 lbs |
| Working Load Limit (lbs.) | 15200 |
| Safety Factor | 5:1 |
| Rated for Overhead Lifting | Yes |
| Diameter | 1-1/4" |
| Length Closed | 36.05" |
| Length Open | 54.25" |
| Body Length | 18" |
| Jaw Opening | 1.73" |
| Turnbuckle Size | 1-1/4" x 18" |
| Pin Size | 1.1" |
| Finish | Galvanized |
| Product Weight | 25.4 lbs. |
| Standards | Meets or exceeds all requirements of ASTM F-1145. |
| Additional Info | Jaw end fitted with nut, bolt, and cotter |
