Low Headroom Adjustable Lifting Beam | 40,000 lb. Capacity | 25' to 30' Spread
$25,145.00
Working Load Limit40,000 lbs
Overall Length367"
MaterialSteel
In stock — ready to ship
Secure checkout with Stripe
Parcel or LTL freight, all 50 states
The Low Headroom Adjustable Lifting Beam - 40,000 lb. Capacity - 25' to 30' Spread is part of our Low Headroom Adjustable line in the Lifting Beams and Spreader Bars department. It is rated with a working load limit of 40,000 lbs. Construction: Steel with a high visibility yellow powder coated paint finish.
Every order ships with the full specification table shown below, and a printable Heavy Haul Rigging spec sheet is available under Documents. Always match the working load limit to your load and inspect gear before each use.
At a glance
- Working Load Limit: 40,000 lbs
- Overall Length: 367"
- Material: Steel
| SKU | LBLHA40K30 |
|---|---|
| Shipping weight | 3,880 lbs |
| Working Load Limit (lbs.) | 40000 |
| Safety Factor | 3:1 |
| Rated for Overhead Lifting | Yes |
| Overall Length | 367" |
| Spread | 25' - 30' |
| Bail Dimensions | Inside Width: 5" Inside Length: 9" Top Thickness: 2.5" Thickness: 1.5" |
| Material | Steel |
| Finish | High visibility yellow powder coated paint |
| Product Weight | 3,880 lbs. |
| Standards | Exceeds all ASME B30.20 and OSHA regulations. Proof loaded per OSHA requirements. |
| Manufacturer Name | M&W |
| Brand Part Number | 24519 |
| Additional Info | WLL (tons): 20 Headroom: 35.1" Spread Adjustment Increments: 6" per side |
